Magnesia alumina bricks use periclase as the main crystal phase and magnesia-alumina spinel as the matrix. They are better in thermal shock resistance than magnesia bricks. In order to improve the thermal shock resistance of magnesia bricks, alumina or alumina is introduced into the ingredients. Bauxite clinker fine powder to form a magnesia-alumina sharp stone matrix, thereby making magnesia-alumina bricks
Magnesium alumina spinel brick for lime kiln
Magnesia alumina bricks use periclase as the main crystal phase and magnesia-alumina spinel as the matrix. They are better in thermal shock resistance than magnesia bricks. In order to improve the thermal shock resistance of magnesia bricks, alumina or alumina is introduced into the ingredients. Bauxite clinker fine powder to form a magnesia-alumina sharp stone matrix, thereby making magnesia-alumina bricks
Index |
MLJ85A |
MLJ93A |
MLJ95A |
MLJ85B |
MLJ93B |
MLJ95B |
MgO%≥ |
85 |
88 |
93 |
82 |
85 |
90 |
Al2O3%≥ |
9 |
5 |
3 |
9 |
5 |
3 |
Fe2O3%≤ |
0.7 |
0.7 |
0.7 |
0.8 |
0.8 |
0.8 |
SiO2≤ |
0.6 |
0.8 |
0.7 |
2.5 |
2 |
2.5 |
Cr2O3≥ |
- |
- |
- |
- |
- |
- |
Apparent porosity%≤ |
16-18 |
16-18 |
16-18 |
17-18 |
17-18 |
17-18 |
Bulk densityg/cm3≥ |
2.85 |
2.85-3.0 |
2.85-3.0 |
2.8 |
2.85-2.95 |
2.85-2.95 |
Normal temperature compressive strength≥ |
45 |
45 |
45 |
40 |
40 |
40 |
0.2Mpa softening temperature under load(T0.6)≥ |
1700 |
1700 |
1700 |
1650 |
1680 |
1680 |
Thermal stability 950℃(风冷) |
100 |
100 |
100 |
80 |
80 |
80 |
The characteristics of magnesia alumina spinel bricks:
Magnesia alumina brick is characterized by good thermal shock resistance
High softening temperature under load
The softening temperature under load is above 1580℃, and the glass has good resistance to invasion.
Application of magnesia aluminum spinel brick
Magnesium-alumina spinel bricks are widely used in steel refining, cement rotary kiln and glass industry dense furnace.
