Castables Refractory for cement kiln

Castables Refractory for cement kiln

Castables for cement kilns are special refractory castables for cement kilns. In my country, the new dry-process cement technology is developing rapidly, and the design and brick shape of PC and SP kilns are also very complicated. In order to adapt to this situation, our factory has developed a series of new refractory castables to replace the traditional refractory materials. Practice has proved that it is more suitable to use castables in parts with complex structure and kiln body deformation. Castables are also suitable for coolers, preheaters, precalciners, kiln door covers, tertiary air ducts and other parts that require thermal insulation. Its varieties include alkali-resistant castables, high-alumina and corundum castables, heat-insulating castables, and steel fiber reinforced refractory castables.

Gongyi Yuying Refractory Co., Ltd. operates: castables for cement kilns, prefabricated blocks, low cement castables, refractory mud, refractory ramming materials, corundum castables, refractory castables, steel fiber castables, steel jade castables, Refractory plastics, high alumina castables, wear-resistant castables, plastics, castables, clay castables, refractory castables manufacturers, the company has 160 employees, including 12 senior professional and technical personnel, with an annual production capacity of 60,000 tons , has light and heavy material production lines, various production, testing and testing equipment, including 10 sets of 400-ton to 1,000-ton series forming presses, two (148 meters long and 118 meters long) high temperature tunnel kiln .

Castables are also suitable for use in some parts of coolers, preheaters, precalciners, kiln door covers and tertiary phoenixes. Suitable thermal insulation castables can be used in preheaters of cement kilns and other parts that require thermal insulation.

The main castables used in cement kilns are:

1. Alkali resistant castable

Experiments show that the alkali pouring material has excellent alkali resistance much better than ordinary clay or high alumina pouring material. Ordinary and low-cement alkali-resistant castables have been successfully used in double-layer structural linings for preheater roofs, cones, tertiary air ducts, etc., where shaped bricks are not suitable. The low-cement alkali-resistant pouring material can also be used in the rear kiln mouth, cooler and kiln door cover.

2. High alumina and corundum castables

High alumina and corundum castables for cement kilns include low cement and ultra-low cement castables, high strength corundum castables, etc. Calcined bauxite and cut jade are used as aggregates in the castable. Low cement and ultra-low cement type high alumina castables can be used in front and rear kiln mouths, chain belts, kiln door covers and cooler side walls.

3. Insulation casting section

The heat-insulating castables for cement kilns include ordinary heat-insulating castables, high-strength heat-insulating castables, and ordinary and low-cement alkali-resistant heat-insulating castables. Usually high alumina cement is used as a binder in the castable. Ordinary heat-insulating castables use expanded perlite, expanded vermiculite and waste light bricks as aggregates. High-strength heat-insulating castables use refractory clay ceramsite, fly ash ceramsite, shale ceramsite, etc. as aggregates. Alkali-resistant and heat-insulating castables use alkali-resistant lightweight aggregates.

Ordinary heat-insulating castables and their prefabricated blocks can be used as heat-insulating villages in double-layer structural linings of coolers, preheaters, calciners, kiln door covers and tertiary air ducts; high-strength heat-insulating castables and their prefabricated Blocks are available as single-layer linings in the neck and disintegration zones of conventional kilns.

Ordinary and low-cement alkali-resistant and heat-insulating castables can be used in preheaters in small and medium-sized kilns and other parts that require alkali-resistant heat insulation.

4. Steel fiber reinforced refractory castables

Adding steel fiber can improve the dismantling strength of the castable, and greatly improve the thermal shock resistance, impact resistance and wear resistance of the castable. Our company has carried out a lot of systematic research on steel fiber reinforced refractory castables, and developed a series of steel fiber reinforced refractory castables.
